Hager MTN110 10A Type B miniature circuit breaker

Hager MTN110 MCB – 10 A Type B, 6 kA Breaker

SKU: MTN110

The Hager MTN110 MCB is a Type B, 10 A single‑pole miniature circuit breaker with 6 kA breaking capacity, ideal for protecting residential lighting and socket circuits.

Available in delivery or click&collect. Click here and ask for a quote!

Check stock Ask for a quote!

£3.60 INC. VAT £3.00 EX. VAT

Description
Additional information

Description

The Hager MTN110 MCB provides reliable protection for domestic circuits. It delivers a 10 A rated current, a Type B tripping curve, and a 6 kA breaking capacity that comply with EN 60898-1 safety standards. Because it mounts quickly onto a DIN rail, the breaker integrates smoothly into consumer units and small distribution boards. Moreover, its compact form saves valuable space while maintaining dependable performance.

Key Features of the Hager MTN110 MCB

Single-Pole Protection: Safeguards individual circuits from faults.
Type B Tripping Curve: Trips at 3–5 times nominal current, making it ideal for household loads.
6 kA Breaking Capacity: Ensures robust protection against short circuits.
DIN-Rail Mounting: Simplifies installation and replacement.
Space-Saving Design: At only 17.5 mm wide, it allows efficient use of panel space.

Technical Specifications – MTN110

Rated Current: 10 A
Rated Operational Voltage: 230/400 V AC
Rated Insulation Voltage: 500 V
Impulse Withstand Voltage: 4 kV
Connection Terminals: Suitable for 1–35 mm² conductors
Operating Temperature: –25 °C to +70 °C
Electrical Endurance: 4,000+ cycles
Protection Level: IP20
Standards: EN 60898-1

Applications & Benefits

The Hager MTN110 MCB suits residential and light commercial installations where dependable circuit protection is essential. It responds quickly to overloads and short circuits, reducing risk and protecting equipment. In addition, the Type B curve is particularly well suited to lighting and socket outlets with moderate inrush currents. Because of its compact width, installers can fit more breakers into smaller panels. As a result, projects save both time and space without compromising safety.

Why Choose Hager MTN110?

Hager has earned a strong reputation for durable and installer-friendly switchgear. The MTN110 breaker reflects this through its ease of installation, compact size, and compliance with safety standards. Furthermore, it provides peace of mind for contractors and homeowners alike. Ultimately, the Hager MTN110 MCB combines reliability, safety, and convenience in one compact device.

Additional information

Product	Circuit Breaker
Product Type	MCB
Pole Configuration	SP
Trip Type	Type B
Short Circuit Rating	6 kA
Cable Capacity	25 (Rigid) 16 (Flexible) mm2
Width	17.5 mm
Depth	68 mm
Current Rating	10 A
Voltage	230\|400 V
CE Approved	Y
Standards	BS EN 60898
Brand	Hager
