Hager JK11004S 100A 4 Pole Switch Incomer Kit

100A Switch Incomer Kit – Hager JK11004S 4 Pole

SKU: JK11004S

Hager JK11004S is a 100A 4 pole switch incomer kit for VML boards. Supplied with DIN rail and terminal shroud. Ensures safe and compliant mains isolation.

100a 4 biegunowe JK1 Zestaw przylotowy

Available in delivery or click&collect. Click here and ask for a quote!

Check stock Ask for a quote!

£72.10 INC. VAT £60.08 EX. VAT

Description
Additional information

Description

100A Switch Incomer Kit – Hager JK11004S for VML Boards

The Hager JK11004S 100A switch incomer kit is designed for full isolation of electrical circuits in VML consumer units. It supports both domestic and small commercial applications where complete disconnection of live and neutral conductors is required.

With a 100A rating and compliance with BS EN 60947-3, this switch provides a safe and regulation-compliant solution. The unit offers four poles, making it ideal for single-phase or three-phase installations where effective and accessible isolation is essential.

Switch Incomer Kit with Full Installation Accessories

This 100A incomer switch kit includes a pre-cut DIN rail and terminal shroud, saving installers time and ensuring safer installation. The DIN rail allows secure mounting within the board, while the terminal cover reduces the risk of accidental contact with live terminals during maintenance or inspection.

Main Isolation Switch for Safe Power Management

Thanks to its four-pole configuration, the JK11004S isolates both line and neutral conductors simultaneously. It provides peace of mind for electricians working under the requirements of the 18th Edition Wiring Regulations. Its compact size ensures it fits cleanly into most Hager VML consumer units without requiring extra space.

Applications and Suitability

This incomer kit is ideal for:

New installations in homes and offices
Upgrades of older boards needing compliant main switches
Boards requiring safe, quick isolation during servicing
Installers working with VML-series units

Technical Details – Hager JK11004S Kit

Current: 100A
Voltage: 230/400V AC
Poles: 4
Standard: BS EN 60947-3
Accessories: DIN rail + terminal shroud
Mounting: DIN rail compatible
Application: VML consumer units
Function: Main isolation switch

Why Choose This 100A Switch Incomer Kit?

If you need a compact, compliant, and ready-to-fit isolation kit, the Hager JK11004S offers a complete solution. With all the key safety components included, this product ensures safe disconnection, fast installation, and full compatibility with VML boards.
