Hager NCN310A 10A 3-pole MCB with C curve and 10/15kA

10A 3-Pole MCB – Hager NCN310A C Curve 10/15kA

SKU: NCN310A

Hager NCN310A is a 10A 3-pole MCB with C curve and dual 10/15kA capacity. Suitable for three-phase protection in commercial and industrial applications.

Available in delivery or click&collect. Click here and ask for a quote!

Check stock Ask for a quote!

£46.04 INC. VAT £38.37 EX. VAT

Description
Additional information

Description

The Hager NCN310A is a compact and high-performance 10A 3-pole MCB (Miniature Circuit Breaker) engineered for protecting three-phase electrical circuits from short circuits and overloads. With its robust design and reliable performance, it is ideal for use in commercial buildings, workshops, and light industrial installations.

Featuring a C curve tripping characteristic, this breaker is designed to tolerate moderate inrush currents—typically caused by inductive loads like small motors, transformers, or fluorescent lighting. It trips between 5 to 10 times its rated current, providing fast fault response without unnecessary interruptions to normal operation.

The NCN310A offers dual breaking capacity ratings:

10kA in compliance with IEC/EN 60898
15kA in compliance with IEC/EN 60947-2

This flexibility ensures the device is suitable for various types of installations with different fault current levels, especially in environments where higher prospective fault currents are expected.

Its 3-module width makes it suitable for DIN rail mounting inside commercial distribution boards and control panels. The MCB is user-friendly, with clear terminal markings and secure screw connections that allow for efficient and safe installation.

Key features:

10A rated current
3-pole (3P) design for three-phase circuits
C curve – ideal for circuits with moderate inrush current
10/15kA short-circuit capacity
3-module compact size
DIN rail mountable
Complies with IEC/EN 60898 and 60947-2
Reliable protection with thermal and magnetic trip mechanisms

Whether you’re protecting lighting banks, small motors, or general distribution in a commercial installation, the Hager NCN310A 10A 3-pole MCB delivers outstanding safety and performance. For any project requiring dependable 10A 3-pole MCB protection, this model is a smart, regulation-compliant choice.

Additional information

Product	Circuit Breaker
Product Type	MCB
Pole Configuration	TP
Mounting	DIN Rail
Trip Type	Type C
Short Circuit Rating	10 kA
Cable Capacity	35 (Rigid) 25 (Flexible) mm2
Width	52.5 mm
Current Rating	10 A
Voltage	230 \| 400 V
Standards	BS EN 60898
Brand	Hager
